All models feature Hawke's new H7 optics with high zoom ratio, supreme clarity and light transmission.
Supreme accuracy for rifle shooting, driven and hunting applications.
- Patented Exposed Zero Lock 'N' Stop Elevation Turret
- 1 Inch Mono-Tube Chassis
- Side Focus
- Illumination
- Wide Angle FOV
- High Volume Eyebox
- 100mm Eye Relief
- Multi-LED High Intensity Reticle
- High Grade, Low Dispersion Crown Glass
- 21 Layer Fully Multi-Coated Lenses
- Zoom Magnification Throw Lever (Removable)
- Fast Focus Eyebell With Lock Ring
- Supplied With Professional Metal Flip-Up Covers.
Â
Mil Pro (20x) Reticle
- Accurate mil spacing on 20x magnification. With half Mil spaced markings extending out to 8 Mil of holdover, the Mil Pro (20x) is a versatile reticle that provides aim points no matter how extreme the distance.
- All reticle measurements are Mil spaced and offer 1 Mil, 0.5 Mil and 0.25 Mil brackets for range finding. Every second Mil spacing on the lower section is numbered to ensure quick and easy acquisition of target and ease of reference.
- Each cross has a see-through gap, allowing an unobstructed view of the target. The thick outer posts are hollowed to ensure they can be seen at all magnifications, without blocking out too much of the view.
- Mil Pro 20x models have additional 1/4 Mil aim points on the center section of the reticle to give even greater precision.
- When on 20x magnification, the Mil spaced reticle and 1/10 MRAD turrets make for easy point of aim adjustment. Every 10 clicks on the turret will measure exactly 1 Mil spacing on the reticle, also known as 1 MRAD.
Specs:
- Objective Lens: 44mm
- Reticle: Mil Pro (20x)
- Parallax: Side Focus
- Magnification: 4 - 20x
- Optical System: System H7
- Scope Tube: 1 Inch
- Illumination: 6 Levels with Off Positions In-between - Red
- Field of View: 28.2 - 5.7ft @100yds, 9.4 - 1.9m @100m
- Field of View: 5.4 - 1.1°
- Eye Relief: 4in, 102mm
- PX/Focus: 10yds - 8, 9m - 8
- Weight: 20.6oz, 584g
- Length: 13.2"", 335mm
- Turret Caps: N/A
- Click Value: 1/ 10MRAD
- Elevation Turret Clicks (max): 19 MRAD
- Windage Turret Clicks (max): 19 MRAD
- Exit Pupil: 0.43 - 0.09"", 11 - 2.2mm
- Ocular Type: Locking Fast Focus
- Power Selector: Knurled Posi-Grip with Removable Zoom Lever
- Lens Coating: Fully Multi-Coated - 21 Layers
- Focal Plane: SFP (Second Focal Plane)
