All models feature Hawke's new H7 optics with high zoom ratio, supreme clarity and light transmission.
Precision build components and larger 34mm monotube construction designed for extreme long range shooting.
- Patented Exposed Zero Lock 'N' Stop Elevation Turret
- First Focal Plane (FFP)
- 34mm Mono-Tube Chassis
- Side Focus
- Illumination
- Wide Angle FOV
- High Volume Eyebox
- 102mm Eye Relief
- Multi-LED High Intensity Reticle
- High Grade, Low Dispersion Crown Glass
- 21 Layer Fully Multi-Coated Lenses
- Zoom Magnification Throw Lever (Removable)
- Fast Focus Eyebell With Lock Ring
- Supplied With Professional Metal Flip-Up Covers.
Â
FFP Mil Pro Ext. Reticle (30x)
- The FFP Mil Pro Ext. reticle was developed specifically for first focal plane optical systems and based around the common principles of Mil spaced reticles. With Mil spaced markings extending out to 15 Mil of holdover, the FFP Mil Pro Ext is a versatile reticle that provides aim points no matter how extreme the distance.
- All reticle measurements are Mil spaced and offer 1 Mil, 0.2 Mil and 0.1 Mil brackets for range finding. Every Mil spacing on the lower section is numbered to ensure quick and easy acquisition of target and ease of reference.
- The thick outer posts are hollowed to ensure they can be seen at all magnifications, without blocking out too much of the view.
Specs:
- Objective Lens: 56mm
- Reticle: FFP Mil Pro Ext. (30x)
- Parallax: Side Focus
- Magnification: 5 - 30x
- Optical System: System H7
- Scope Tube: 34mm
- Illumination: 11 Levels with Off Positions In-between - Red
- Field of View: 22.5 - 3.8ft @100yds, 7.5 - 1.3m @100m
- Field of View: 4.3 - 0.7°
- Eye Relief: 4in, 102mm
- PX/Focus: 15yds - 8, 14m - 8
- Weight: 29.3oz, 830g
- Length: 15.4"", 392mm
- Turret Caps: N/A
- Click Value: 1/ 10MRAD
- Elevation Turret Clicks (max): 29 MRAD
- Windage Turret Clicks (max): 15 MRAD
- Exit Pupil: 0.44 - 0.07"", 11.2 - 1.9mm
- Ocular Type: Locking Fast Focus
- Power Selector: Knurled Posi-Grip with Removable Zoom Lever
- Lens Coating: Fully Multi-Coated - 21 Layers
- Focal Plane: FFP (First Focal Plane)
